Dwyer UV-1112 Ultra-View Polysulfone Flowmeter

Rp5.360.000

1 in stock

Category:

Description

Service:
Compatible liquids or gases.
Wetted Materials:
Polysulfone body and fittings, fluoroelastomer O-rings and virgin PTFE float.
Temperature Limits:
35 to 212F (2 to 100C); 35 to 130F (2 to 54C) for PVC fitting option.
Pressure Limits:
150 psi (10.34 bar).
Accuracy:
2% FS @ 70F 2F (21.1C) and 14.7 psia (in line connection rating only).
Repeatability:
1% FS @ 70 2F (21.1C) and 14.7 psia (in line connection rating only).
Process Connections:
1″ female NPT. Optional 90 polysulfone elbow – 1″ male NPT.
Scale Length:
6″ (152.40 mm) – 7″ (177.80 mm), depending on model.
Fitting Torque:
Maximum 22 ft lb.
