Dwyer THC-P Temperature/Humidity Switch

Rp1.480.000

5 in stock

Category:

Description

THC-P Humidity probe, 3 V output, 4 ft (1.2 m) cable

The SERIES THC simultaneously measures and controls temperature and humidity. The unit offers a 3-digit red display for temperature indication and a 3-digit green display indicating humidity.

Specifications

Measurement Range: Temperature: -58 to 302F (-50 to 150C); Humidity: 10 to 100% RH.
Input: Up to 2 thermistors and 1 humidity sensor.
Output: 4 SPST, 8 A relays @ 250 VAC.
Horsepower Rating (HP): 1/3 HP.
Control Type: On/Off direction, direct or reverse acting, neutral.
Power Requirements: 110 or 230 VAC (depending on model).
Accuracy: Temperature: 0.5% of probe range; Humidity: 3% (20 to 90%) of range.
Display: Two 3-digit displays. 1/2″ digits.
Resolution: 0.1.
Memory Backup: Nonvolatile memory.
Ambient Operating Temperature: 32 to 158F (0 to 70C).
Storage Temperature: -4 to 176F (-20 to 80C).
Panel Cutout: 5.15″ x 3.97″ (131 x 101 mm).
Front Panel Protection: IP64.
Agency Approvals: CE.
